AV4NPTV1/2"-VSSS-L745/12-V44A
Float Switch Type FLS-SA
Material: Stainless steel 316Ti (EN 1.4571)
Pressure: 1 bar
Temperature range: -20°C up to 80°C
Fluid density: 1000 kg/m3
Housing: Stainless steel
Ingress protection: IP66/68
Electrical connection: M20 x 1.5 mm with cable gland
Process connection: Mounting thread downwards 1/2"NPT
Switch function 1: Closing on rising level (SPST) 200 mm
Switch function 2: Closing on rising level (SPST) 500 mm
Switch function 3: Closing on rising level (SPST) 700 mm
Switch rating: max. AC 230V; 100VA; 1A / DC 230V; 50W; 0.5A
Float: Stainless steel 316Ti V44A; Float outer diameter: 44 mm
Number of floats: 2 pcs
Guide tube: OD 12 mm Insertion length (L): 745 mm
Float stop: Float collar
Weight: 1.4 kg
